Cable Parameter

• Fiber Count: 12Core
• Colored Coating Fiber :

Dimension: 250μm±15μm

Color: Blue, Orange, Green, Brown, Gray, White, Red, Black, Yellow, Purple, Pink, Aqua blue

• Loose Tube:

Dimension: 2.8mm±0.1mm

Material: PBT

Tube Color: Blue, orange, green, brown

Loose tube number: 1

Filling rope number: 1

The fiber in loose tube number: 12

• Material of reinforcement: Phosphating steel wire 1.0mm
• Outer / Inner Jacket :

Diameter: Inner1.6mm±0.10mm/Outer1.7mm±0.10mm

Material: HDPE

Sheath color: Black

Line color: Yellow

• Sheath outer diameter: 12.5mm±0.2mm
